C64 Mainboard Assy No. 250425 “Repair”

Repairing the old Commodore C64 a few months back was a lot of fun and I learned much about the old machines in the process. Now I wanted a new challenge and so I bought a C64 motherboard Assy No. 250425 on eBay. The board came without case, keyboard or any other accessories and it was advertised as “defective”. No other description besides “as depicted”.

Continue reading

C64 Expansion Port Expander Research

Expansion port expanders are adapters which allow multiple cartridges to be attached physically to the C64 at the same time. In rare cases, two of those cartridges will then be usable simultaneously, for the majority of cases the expander allows the user to switch between them.

I’ve never owned one of these devices but I’ve been toying with the idea to create my own for a while. Recently then, a generous person donated a bunch of 44 pin board edge connectors that would be required to build it. So I started to take a closer look at existing implementations, from the past and present.

Continue reading

Pi1541io Revision 2

On Friday, I received the prototype batch of PCBs for the second revision of my IO Adapter for the Pi1541 project. Today, I finally found the time to assemble a couple of those boards and so far, everything seems to be working great!

Two working configurations of the Pi1541 IO Adapter.

When assembling one of the rev.2 boards, there are multiple alternative configuration to chose from. One of the simplest working ones — shown on the left side in the photo above — needs only three components: a 6 pin DIN connector, a 4 channel level shifter module, and a 40 pin female header to connect to the Raspberry Pi. Most of the possible configurations can be built using easy to solder through-hole components, only! Continue reading
